Third-party network cameras supported
• Supports live view, storage, and playback of the connected camera at up to 8 MP resolution
• Connectable to smart IP cameras from Hikvision and the recording, playing back, and backing up of VCA alarms can be
realized
• VCA detection alarm is supported
• Hik-Connect for easy network management
Video/Audio Input |
Two-way audio input: |
|
1-ch, RCA (2.0 Vp-p, 1kΩ) |
IP video input: |
|
16-ch |
Network |
Incoming bandwidth: |
|
160Mbps |
Outgoing bandwidth: |
|
80Mbps |
Video/Audio Output |
HDMI Output: |
|
1-ch, resolution:4K (3840 × 2160)/30Hz,1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 ×1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz. |
Recording Resolution: |
|
8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
VGA Output: |
|
1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
Decoding |
Decoding format: |
|
H.265/H.265+/H.264/H.264+/MPEG4 |
Capability: |
|
1-ch @ 8 MP / 4-ch @ 1080p |
Hard Disk |
SATA: |
|
2 SATA interfaces |
Capacity: |
|
Up to 6TB capacity for each HDD |
External Interface |
Network Interface: |
|
1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface |
USB Interface: |
|
2, USB2.0 |
POE |
Supported Standard: |
|
AF and AT |
Interface: |
|
24 independent 10/100 Mbps PoE Ethernet interfaces |
General |
Power Supply: |
|
100 to 240 VAC |
Power: |
|
≤ 280W |
Consumption(without hard disk and POE): |
|
≤ 15W |
Working Temperature: |
|
-10 oC ~ +55 oC (+14 oF~ + 131 oF) |
Working Humidity: |
|
10 % ~ 90 % |
Chassis: |
|
1U chassis |
Dimensions: |
|
385 × 315 × 52 mm (15.2"× 12.4" × 2.0") |
Weight(without HDD): |
|
≤ 3 kg (6.6 lb) |
